Introduction of Function of Bubble Washing Machine

Introduction of Function of Bubble Washing Machine

Bubble washing machine uses the lower part of mesh belt conveyor to immerse under the water surface of the washing tank. The outlet of the blower is connected from the side of the conveyor belt to the blowing pipe in the middle of the conveyor belt. There are small holes in the blowing pipe. The air from the blower is blown out through many small holes in the bubble pipe and stirred violently through the mesh belt.

When working, the motor drives the drum to drive the conveyor belt to run, and the blower also starts. The cleaned material is put into the lower horizontal section of the conveyor. In the washing tank, the air from the blower stirs the water violently and flushes the dirt on the surface of the material. Then, with the movement of the conveyor belt, the material is sent to the inclined section of the conveyor belt to feed the material by the sprinkler pipe. Clean and then complete the cleaning process.

There is a bubble generator in the bubble washing machine, which makes the material roll over and removes the residual chemicals on the surface of the product. At the same time, appropriate amount of medicines can be added to disinfect and fix the color. Floating matter can overflow from overflow chute and sediment can be discharged from sewage outlet to achieve the purpose of cleaning. It has the characteristics of high cleanliness, power saving, water saving and stable and reliable equipment. Working principle Material enters the flume, under the action of high-pressure water flow and strong bubbles, it is fully dispersed, rolled, cleaned and transmitted. The sediment washed from the surface of the material sinks into the bottom isolation bin, so that no overturning and reflux will occur, which will cause re-pollution. The material washed by the bubble washing machine is washed out and then sprayed and sent to the next process.
